BDD Requirements Management with JBehave, Thucydides and JIRA – Part 2


Thucydides is an open source library designed to make practicing Behaviour Driven Development easier. Thucydides plays nicely with BDD tools such as JBehave, or even more traditional tools like JUnit, to make writing automated acceptance tests easier, and to provide richer and more useful living documentation. In this series of articles, we look at the tight one and two-way integration that Thucydides offers with JIRA. The first article discussed basic one-way integration with JIRA. In this article, we will looking at taking that integration further. We will see how to insert links to the Thucydides reports into JIRA, how to update the state of JIRA issues based on the Thucydides test outcomes, and how to report on JIRA versions and releases in the Thucydides reports.

The rest of this article assumes you have some familiarily with Thucydides. For a tutorial introduction to Thucydides, check out the Thucydides Documentation or this article for a quick introduction.

The simplest form of two-way integration between Thucydides and JIRA is to get Thucydides to insert a comment containing links to the Thucydides test reports for each related issue card. To get this to work, you need to tell Thucydides where the reports live. One way to do this is to add a property calledthucydides.public.url to your thucydides.properties file with the address of the thucydides reports.

thucydides.public.url=http://buildserver.myorg.com/latest/thucydides/report

This will tell Thucydides that you not only want links from the Thucydides reports to JIRA, but you also want to include links in the JIRA cards back to the corresponding Thucydides reports. When this property is defined, Thucydides will add a comment like the following to any issues associated with the executed tests:

images/jira-thucydides-comment.png

The thucydides.public.url will typically point to a local web server where you deploy your reports, or to a path within your CI server. For example you could publish the Thucydides reports on Jenkins using theJenkins HTML Publisher Plugin, and then add a line like the following to your thucydides.properties file:

thucydides.public.url=http://jenkins.myorg.com/job/myproject-acceptance-tests/Thucydides_Report/

If you do not want Thucydides to update the JIRA issues for a particular run (e.g. when running your tests locally), you can also set thucydides.skip.jira.updates to true, e.g.

thucydides.skip.jira.updates=true

This will simply write the relevant issue numbers to the log rather than trying to connect to JIRA.

Updating JIRA issue states

You can also configure the plugin to update the status of JIRA issues. This is deactivated by default: to use this option, you need to set the thucydides.jira.workflow.active option to true, e.g.

thucydides.jira.workflow.active=true

The default configuration will work with the default JIRA workflow: open or in progress issues associated with successful tests will be resolved, and closed or resolved issues associated with failing tests will be reopened. If you are using a customized workflow, or want to modify the way the transitions work, you can write your own workflow configuration. Workflow configuration uses a simple Groovy DSL. The following is an example of the configuration file used for the default workflow:

    when 'Open', {
        'success' should: 'Resolve Issue'
    }

    when 'Reopened', {
        'success' should: 'Resolve Issue'
    }

    when 'Resolved', {
        'failure' should: 'Reopen Issue'
    }

    when 'In Progress', {
        'success' should: ['Stop Progress','Resolve Issue']
    }

    when 'Closed', {
        'failure' should: 'Reopen Issue'
    }

You can write your own configuration file and place it on the classpath of your test project (e.g. in theresources directory). Then you can override the default configuration by using thethucydides.jira.workflow property, e.g.

thucydides.jira.workflow=my-workflow.groovy

Alternatively, you can simply create a file called jira-workflow.groovy and place it somewhere on your classpath (e.g. in the src/test/resources directory). Thucydides will then use this workflow. In both these cases, you don’t need to explicitly set the thucydides.jira.workflow.active property.

Release management

In JIRA, you can organize your project releases into versions, as illustrated here:

images/jira-versions.png

You can and assign cards to one or more versions using the Fix Version/s field:

images/jira-fix-versions.png

By default, Thucydides will read version details from the Releases in JIRA. Test outcomes will be associated with a particular version using the “Fixed versions” field. The Releases tab gives you a run-down of the different planned versions, and how well they have been tested so far:

images/releases-tab.png

JIRA uses a flat version structure – you can’t have for example releases that are made up of a number of sprints. Thucydides lets you organize these in a hierarchical structure based on a simple naming convention. By default, Thucydides uses “release” as the highest level release, and either “iteration” or “sprint” as the second level. For example, suppose you have the the following list of versions in JIRA – Release 1 – Iteration 1.1 – Iteration 1.2 – Release 2 – Release 3

This will produce Release reports for Release 1, Release 2, and Release 3, with Iteration 1.2 and Iteration 1.2 appearing underneath Release 1. The reports will contain the list of requirements and test outcomes associated with each release. You can drill down into any of the releases to see details about that particular release

images/releases.png

You can also customize the names of the types of release usinge the thucydides.release.typesproperty, e.g.

thucydides.release.types=milestone, release, version

Conclusion

Thucydides has powerful one and two-way integration with JIRA. In these articles, we have seen how you can incoporate links from Thucydides to JIRA, from JIRA to Thucyides, and even update the status of issues in JIRA based on the test results. And, if you are managing your versions in JIRA, you can also report on how well each version has been tested, and what remains to be tested before the next release.

Want to learn more? Be sure to check out the Thucydides web site, the Thucydides Blog, or join theThucydides Google Users Group to join the discussion with other Thucydides users.

Wakaleo Consulting, the company behind Thucydides, also runs regular courses in Australia, London and Europe on related topics such as Agile Requirements GatheringBehaviour Driven DevelopmentTest Driven Development, and Automated Acceptance Testing.

10
Jul

New Thucydides release: 0.9.260


This new release integrates Selenium 2.42.2, has improved reporting, a number of improvements to the internal APIs, and addresses a number of issues and improvements. Some of the more notable ones include:

  • THUCYDIDES-242 - Need some way to obtain current TestStep within custom StepListener: You can get (a copy of) the current test step by calling
    StepEventBus.getEventBus().getCurrentStep()
  • THUCYDIDES-192 - Fixed a reporting issue when multiple features or stories had identical names
  • THUCYDIDES-232 - get page source on step failure: You can retrieve the page source of the latest step using the StepEventBus.getEventBus().getCurrentStep() method.
  • THUCYDIDES-148 - Thucydides.ignoredStep should not be marked as pended: Thucydides now handles failed assumptions (e.g  Assume.assumeThat(true, is(false))) in JUnit correctly. Tests with failing assumptions are marked as skipped and reported with an “assumption violation” error.
  • THUCYDIDES-35 - Allow using multibyte charactor in class name and method name.
  • THUCYDIDES-151 - Report aggregate – Running test with parametrized test data seems to have a limitation of 10 parameter pairs
  • THUCYDIDES-177 - Report groups test cases for data-driven tests using a CSV file
  • THUCYDIDES-214 - thucydides-jira-plugin produces wrong test ID in link posted back to JIRA when using ParameterizedRunner
  • THUCYDIDES-235 - Incorrect result appears in log in case if one “Step” using another “Step” (substep)
  • THUCYDIDES-227 - Show/hide tags on the main report page

Other fixes/improvements include

  • THUCYDIDES-88 logback.groovy in thucydides-core breaks application logging configuration
  • THUCYDIDES-239 Better exception reporting in ResizableImage
  • THUCYDIDES-228 Don`t write qualifier in console log for DDT Tests
  • THUCYDIDES-240 BeanMatcher throws IllegalArgumentException for field names containing dots (or opening parenthesis / square bracket)

Enjoy!

10
Jul

BDD Requirements Management with JBehave, Thucydides and JIRA – Part 1


Thucydides is an open source library designed to make practicing Behaviour Driven Development easier. Thucydides plays nicely with BDD tools such as JBehave, or even more traditional tools like JUnit, to make writing automated acceptance tests easier, and to provide richer and more useful living documentation. In a series of two articles, we will look at the tight one and two-way integration that Thucydides offers with JIRA.

The rest of this article assumes you have some familiarily with Thucydides. For a tutorial introduction to Thucydides, check out the Thucydides Documentation or this article for a quick introduction.

Getting started with Thucydides/JIRA integration

Atlassian JIRA

JIRA is a popular issue tracking system that is also often used for Agile project and requirements management. Many teams using JIRA store their requirements electronically in the form of story cards and epics in JIRA

Suppose we are implementing a Frequent Flyer application for an airline. The idea is that travellers will earn points when they fly with our airline, based on the distance they fly. Travellers start out with a “Bronze” status, and can earn a better status by flying more frequently. Travellers with a higher frequent flyer status benefit from advantages such as lounge access, prioritized boarding, and so on. One of the story cards for this feature might look like the following:

images/jira-story.png

This story contains a description following one of the frequently-used formats for user story descriptions (“as a..I want..so that”). It also contains a custom “Acceptance Criteria” field, where we can write down a brief outline of the “definition of done” for this story.

These stories can be grouped into epics, and placed into sprints for project planning, as illustrated in the JIRA Agile board shown here:

images/jira-agile.png

As illustrated in the story card, each of these stories has a set of acceptance criteria, which we can build into more detailed scenarios, based on concrete examples. We can then automate these scenarios using a BDD tool like JBehave.

The story in Figure 1 describes how many points members need to earn to be awarded each status level. A JBehave scenario for the story card illustrated earlier might look like this:

Frequent Flyer status is calculated based on points

Meta:
@issue FH-17

Scenario: New members should start out as Bronze members
Given Jill Smith is not a Frequent Flyer member
When she registers on the Frequent Flyer program
Then she should have a status of Bronze

Scenario: Members should get status updates based on status points earned
Given a member has a status of <initialStatus>
And he has <initialStatusPoints> status points
When he earns <extraPoints> extra status points
Then he should have a status of <finalStatus>
Examples:
| initialStatus | initialStatusPoints | extraPoints | finalStatus | notes                    |
| Bronze        | 0                   | 300         | Silver      | 300 points for Silver    |
| Silver        | 0                   | 700         | Gold        | 700 points for Gold      |
| Gold          | 0                   | 1500        | Platinum    | 1500 points for Platinum |

Thucydides lets you associate JBehave stories or JUnit tests with a JIRA card using the @issue meta tag (illustrated above), or the equivalent @Issue annotation in JUnit. At the most basic level, this will generate links back to the corresponding JIRA cards in your test reports, as illustrated here:

images/jira-test-report.png

For this to work, Thucydides needs to know where your JIRA server. The simplest way to do this is to define the following properties in a file called thucydides.properties in your project root directory:

jira.url=https://myserver.atlassian.net
jira.project=FH
jira.username=jirauser
jira.password=t0psecret

You can also set these properties up in your Maven pom.xml file or pass them in as system properties.

Thucydides also supports two-way integration with JIRA. You can also get Thucydides to update the JIRA issue with a comment pointing to the corresponding test result.

Feature Coverage

But test results only report part of the picture. If you are using JIRA to store your stories and epics, you can use these to keep track of progress. But how do you know what automated acceptance tests have been implemented for your stories and epics, and, equally importantly, how do you know which stories or epics have no automated acceptance tests? In agile terms, a story cannot be declared “done” until the automated acceptance tests pass. Furthermore, we need to be confident not only that the tests exist, but they test the right requirements, and that they test them sufficiently well.

We call this idea of measuring the number (and quality) of the acceptance tests for each of the features we want to build “feature coverage”. Thucydides can provide feature coverage reporting in addition to the more conventional test results. If you are using JIRA, you will need to add thucydides-jira-requirements-provider to the dependencies section of your pom.xml file:

        <dependencies>
            ...
            <dependency>
                <groupId>net.thucydides.plugins.jira</groupId>
                <artifactId>thucydides-jira-requirements-provider</artifactId>
                <version>0.9.262</version>
            </dependency>
        </dependencies>

(The actual version number might be different for you – always take a look at Maven Central to know what the latest version is).

You will also need to add this dependency to the Thucydides reporting plugin configuration:

        <build>
            ...
            <plugins>
                ...
                <plugin>
                    <groupId>net.thucydides.maven.plugins</groupId>
                    <artifactId>maven-thucydides-plugin</artifactId>
                    <version>0.9.262</version>
                    <executions>
                        <execution>
                            <id>thucydides-reports</id>
                            <phase>post-integration-test</phase>
                            <goals>
                                <goal>aggregate</goal>
                            </goals>
                        </execution>
                    </executions>
                    <dependencies>
                        <dependency>
                            <groupId>net.thucydides.plugins.jira</groupId>
                            <artifactId>thucydides-jira-requirements-provider</artifactId>
                            <version>0.9.262</version>
                        </dependency>
                    </dependencies>
                </plugin>
            </plugins>
        </build>

Now, when you run the tests, Thucydides will query JIRA to determine the epics and stories that you have defined, and list them in the Requirements page. This page gives you an overview of how many requirements (epics and stories) have passing tests (green), how many have failing (red) or broken (orange) tests, and how many have no tests at all (blue):

images/requirements-view.png

If you click on an epic, you can see the stories defined for the epic, including an indicator (in the “Coverage” column) of how well each story has been tested.

images/epic-details.png

From here, you may want to drill down into the details about a given story, including what acceptance tests have been defined for this story, and whether they ran successfully:

images/story-report.png

Both JIRA and the JIRA-Thucydides integration are quite flexible. We saw earlier that we had configured a custom “Acceptance Criteria” field in our JIRA stories. We have displayed this custom field in the report shown above by including it in the thucydides.properties file, like this:

jira.custom.field.1=Acceptance Criteria

Thuydides reads the narrative text appearing in this report (“As a frequent flyer…”) from the Descriptionfield of the corresponding JIRA card. We can override this behavior and get Thucydides to read this value from a different custom field using the jira.custom.narrative.field property. For example, some teams use a custom field called “User Story” to store the narrative text, instead of the Description field. We could get Thucydides to use this field as follows:

jira.custom.narrative.field=User Story

Conclusion

Thucydides has rich and flexible one and two-way integration with JIRA. Not only can you link back to JIRA story cards from your acceptance test reports and display information about stories from JIRA in the test reports, you can also read the requirements structure from JIRA, and report on which features have been tested, and which have not.

In the next article in this series, we will learn how to insert links to the Thucydides reports into the JIRA issues, and how to actively update the state of the JIRA cards based on the outcomes of your tests.

Want to learn more? Be sure to check out the Thucydides web site, the Thucydides Blog, or join theThucydides Google Users Group to join the discussion with other Thucydides users.

Wakaleo Consulting, the company behind Thucydides, also runs regular courses in Australia, London and Europe on related topics such as Agile Requirements GatheringBehaviour Driven DevelopmentTest Driven Development, and Automated Acceptance Testing.

7
Mar

Thucydides version 0.9.235 Released


A new version of Thucydides is out (version 0.9.235), with bug fixes and new features!

Bug fixes

The bug fixes include:

  • THUCYDIDES-226 and THUCYDIDES-224: You can now pass arbitrarily complex chrome switches in the ‘chrome.switches’ property, containing spaces, commas etc, e.g.
    –user-agent=Mozilla/5.0 (Linux; Android 4.0.4; Galaxy Nexus Build/IMM76B)AppleWebKit/535.19 (KHTML, like Gecko) Chrome/18.0.1025.133 MobileSafari/535.19

  • THUCYDIDES-215 – Provided drivers can take screenshots
  • THUCYDIDES-225 – The webdriver.timeouts.implicitlywait system property now works to configure the timeout value of a PageObject.
  • THUCYDIDES-223 – You can now pass absolute path values in the thucydides.driver.capabilities system property.
  • Session data and step libraries are cleared between unit tests: A bug in previous versions of Thucydides meant that session data (accessed via the Thucydides.getCurrentSession() method) and step libraries were preserved between session states. This could occasionally cause problems, so session data is now cleared between each test in both JUnit and JBehave. This can be deactivated by setting the ‘thucydides.maintain.session’ property to true. Step libraries are now always reinitialized between scenarios or tests.

    THUCYDIDES-215 deserves some more detail. You can add your own custom WebDriver provider by implementing the DriverSource interface. First, you need to set up the following system properties (e.g. in your ‘thucydides.properties’ file):

    webdriver.driver = provided
    webdriver.provided.type = mydriver
    webdriver.provided.mydriver = com.acme.MyPhantomJSDriver
    thucydides.driver.capabilities = mydriver

    Previously, it was hard to configure Thucydides to take screenshots using provided drivers. Now, you implement the DriverSource interface (as before), but with the new takesScreenshots() method:

    public class MyPhantomJSDriver implements DriverSource {

        @Override
        public WebDriver newDriver() {
            try {
                DesiredCapabilities capabilities = DesiredCapabilities.phantomjs();

                // doesn't work :(
                capabilities.setCapability(CapabilityType.TAKES_SCREENSHOT, true);

                return new PhantomJSDriver(ResolvingPhantomJSDriverService.createDefaultService(),
                        capabilities);
            }
            catch (IOException e) {
                throw new Error(e);
            }
        }

    	@Override
        public boolean takesScreenshots() {
            return true;
        }
    }

    This driver will now take screenshots normally.

    New Features

    And two cool new features:

    Custom messages for WebElementFacade assertions

    Normally, to check the state of a WebElementFacade, you do something like this:

    @FindBy(css=".whatever")
    WebElementFacade myfield;
    ...
    myField.shouldBeVisible();

    But in this case, the error message was always the same. Now you can also do this:

    myField.expect("My field should be visible").shouldBeVisible();

    This will work for any of the "should"-style methods (shouldBeVisible, shouldContainText, etc.).

    Clever reuse of screenshots

    In previous versions, Thucydides recorded a different set of screenshots for each test run. This could lead to a lot of screenshots and the need for very large disks. Now, if screenshots are identical (i.e. if they have the same MD5 digest), the same file will be used.

31
Dec

Thucydides Release 0.9.229


There have been many releases since the last release notes were published, so this entry will summarize some of the highlights that are included in release 0.9.229 (though many came out in releases previous to that). Some of the highlights include:

  • Added support for Selenium 2.39.0
  • Testing AngularJS is made easier with support for the ng-model attribute in the Thucydides @FindBy annotation. Suppose you have this AngularJS input field:
<input ng-model="angularField" value="Model value" />

You can now find this directly using the Thucydides @FindBy:

import net.thucydides.core.annotations.findby.FindBy
 @FindBy(ngModel = "angularField")
 public WebElementFacade ngModelField;
  • Support for nested page objects – you can have page object fields inside other page objects. This makes it easier to write page objects for smaller reusable sections of the screen.
  • You don’t need to override the constructors for ScenarioSteps and PageObjects any more
  • You can provide your own webdriver instance using the ‘webdriver.provided.type’. Just implement the DriverSource interface. For example, you could implement a class like this:
package com.acme
public class MyFunkyDriverSourceImpl implements DriverSource {
    public WebDriver newDriver() {
       return new FunkyWebDriver();
    }
}

Then just run the tests with the following properties (e.g. in the thucyiddes.properties file or on the command line):

webdriver.driver = provided
 webdriver.provided.type = funky
 webdriver.provided.funky = com.acme.MyFunkyDriverSourceImpl
  • Lots of improvements to the reports, including:
    • Reports now have the option to hide the pie chart on the aggregate pages
    • Test reports now display the date and time of the report generation on each page.
    • You can use the ‘show.related.tags’ system property to display (default) or hide related tag statistics on the dashboard
    • Support for reporting on releases/versions by integrating with JIRA (there will be a full article on this feature shortly)
    • Support for integration with 3rd party test management software such as the JIRA Zephyr plugin to report on manual as well as automated tests
  • Many bug fixes

If you are still on an older version, update your dependencies today!

19
May

Thucydides Release 0.9.125


We made several minor releases in the last two months.  The latest release version is 0.9.125 which is now available for download. Here is a list of some of the key features and bug fixes added recently.

More flexible Examples tables for data-driven tests on the details page

Examples table now supports pagination, sorting of columns and text search.

Examples table with pagination, sorting and text search

Examples table with pagination, sorting and text search

Better handling of foreign characters in reports

Reports now display non-English characters properly.

Before

Before

After

After

Test results can be downloaded

The main report page now has a link to download test results in CSV format.

Test results can be downloaded in CSV format

Test results can be downloaded in CSV format

Fluent field entry using into a WebElementFacade

A new method has been added to provide a more fluid way to enter data in a web element facade. The following code snippet will explain.


...

page.enter("some value").into(facade);

...

Support for GivenStories in jBehave stories

jBehave style GivenStories keyword can now be used in .story files. GivenStories is used to specify pre-requisites for a story in jBehave. This is a very useful feature of jBehave that helps organize the stories better and reduces duplication. See here for examples.

Filter tests by tag in jUnit

You can now filter tests by tag while running Thucydides. This can be achieved by providing a single tag or a comma separated list of tags from command line. If provided, only classes and/or methods with tags in this list will be executed.

Example:

mvn verify -Dtags="iteration:I1"

or

mvn verify -Dtags="color:red,flavor:strawberry"

Support for jUnit Assumptions

If steps include junit style assumptions, then those steps where the conditions under assumptions fail are marked as PENDING instead of ERROR. Subsequent steps are also marked as PENDING.

Bug Fixes

  • Thucydides-146: Fixed a bug that caused chromedriver to fail with error message “Error communicating with the remote browser. It may have died” when @Managed(uniqueSession) was set to true.
  • Thucydides-149: Fixed a bug due to which test where no steps were executed due to error was reported as pending in the aggregate report.
  • Thucydides-150: Tests where no steps ae executed due to errors now show relevant exception cause in the report. Earlier the test was reported as error but no details were provided.
  • Thucydides-152 : XML reports now support UTF-8 encoding.
  • Thucydides-155: Fixed a bug that prevented webdriver from correctly restarting for parameterized tests even when thucydides.restart.browser.frequency property is set to 1
  • Thucydides-158 : Fixed a bug that was causing reports to throw errors for data-driven tests when @TestData contained an array.
12
Mar

It ain’t just reds and greens: Automated Acceptance Testing and quaternary test outcomes


Although they seem simple enough on the surface, test outcomes are actually quite complicated beasts. Traditional unit tests, and basic TDD tests, have just two states, passing or failing, represented by red and green in the famous “RED-GREEN-REFACTOR” dicton. In Behaviour Driven Development (BDD), on the other hand, we have the additional concept of ‘pending’ tests: tests that have been specified (for example, in a Cucumber or JBehave story) but not yet implemented. When we report on test results, we need to be able to distinguish these three states, as a pending test has very different semantics to a failing test. Pending means it’s not yet done yet, but this may well be as expected, especially towards the start of a sprint. A failing test, on the other hand, needs fixing. Now.

Most BDD tools, such as Cucumber, JBehave, Concordion, easyb and so forth, report test results in terms of these three states. However, the complexity doesn’t stop here. Maintaining web tests, for example, requires ongoing effort, and can perturb the test reporting if not handed with care. For example, if a web page changes during normal development or refactoring work, the tests that use this page may break. Although good software engineering practices such as the use of Page Objects can reduce the risk of this quite a bit, and reduce the work involved in maintaining the tests when it does, it is still something that will happen regularly. And again, the semantics of a test that is broken is quite different to those of a failing test. A broken test needs maintenance work on the test suite. It may also mask an application error, but you will need to investigate to find out. A failing test means that the application is broken, and therefore needs urgent fixing.

In an attempt to address this limitation in conventional BDD reporting, Thucydides now distinguishes between test failures (triggered by an assertion error) from test errors (triggered by any other exception). When you run your automated acceptance tests using Thucydides, any error that triggers an AssertionError (or a subclass of AssertionError) will be considered a test failure. Anything else (such as the NotFoundException, when an element is not found on the page) is considered to be an error, and therefore indicative of a broken test.

In the future we may extend Thucydides further to make this concept more configurable: for example, so that users can provide exceptions that should be considered as either an error or a test failure, or even adding additional outcome states (e.g infrastructure failure, database not setup, etc.).

9
Mar

Thucydides Release 0.9.103 – Improved reporting, other enhancements and bug fixes


Thucydides Release 0.9.103 adds some useful new features and enhancements.

Reports distinguish between errors and failures

Test reports now distinguish between test errors and failures. The following screenshot will make this clear.

Reports distinguish between Test Errors and Failures

Reports distinguish between Test Errors and Failures

Detailed report will not show screenshots column if there are no screenshots in the test

Tests that do not have any screenshots will no longer show an empty screenshots column in the details page.

no-screenshots-column

Injecting WebElementFacades in Page objects

Instead of declaring WebElement variables in Page Objects and then calling element() or $() to wrap them in WebElementFacades, you can now declare WebElementFacade variables directly inside the Page Objects. This will make the Page Object code simpler more readable.

So, instead of writing


@DefaultUrl("http://en.wiktionary.org/wiki/Wiktionary:Main_Page")
public class DictionaryPage extends PageObject {

    @FindBy(name="search")
    private WebElement searchTerms;

    private WebElement go;    //variable name matches element id or name

    public DictionaryPage(WebDriver driver) {
        super(driver);
    }

    public void enter_keywords(String keyword) {
        element(searchTerms).type(keyword);
    }

    public void lookup_terms() {
        element(go).click();
    }

    public List getDefinitions() {
        WebElement definitionList = getDriver().findElement(By.tagName("ol"));
        List<WebElement> results = definitionList.findElements(By.tagName("li"));
        return convert(results, toStrings());
    }

    private Converter<WebElement, String> toStrings() {
        return new Converter<WebElement, String>() {
            public String convert(WebElement from) {
                return from.getText();
            }
        };
    }
}

you can write

@DefaultUrl("http://en.wiktionary.org/wiki/Wiktionary:Main_Page")
public class DictionaryPage extends PageObject {

    @FindBy(name="search")
    private WebElementFacade searchTerms;

    private WebElementFacade go;       //variable name matches element id or name

    public DictionaryPage(WebDriver driver) {
        super(driver);
    }

    public void enter_keywords(String keyword) {
        searchTerms.type(keyword);  //directly use facade
    }

    public void lookup_terms() {
        go.click();                //directly use facade
    }

    public List getDefinitions() {
        WebElement definitionList = getDriver().findElement(By.tagName("ol"));
        List<WebElement> results = definitionList.findElements(By.tagName("li"));
        return convert(results, toStrings());
    }

    private Converter<WebElement, String> toStrings() {
        return new Converter WebElement, String>() {
            public String convert(WebElement from) {
                return from.getText();
            }
        };
    }
}

Switching to another page object

A new method, switchToPage() has been added to PageObject class to make it convenient to return a new PageObject after navigation from within a method of a PageObject class. For example,

@DefaultUrl("http://mail.acme.com/login.html")
public class EmailLoginPage extends PageObject {

    ...
    public void forgotPassword() {
        ...
        forgotPassword.click();
        ForgotPasswordPage forgotPasswordPage = this.switchToPage(ForgotPasswordPage.class);
        forgotPasswordPage.open();
        ...
    }
    ...
}

Other minor enhancements and bug fixes

  • Selenium version updated to 2.31.0.
  • Added containsOnlyText and shouldContainOnlyText methods to WebElementFacade. These methods are similar to containsText/shouldContainText methods but check for exact match.
  • Modified shouldContainText method in WebElementFacade so that error message shows both the expected text, and the text found in the element.
  • Fixed a bug in the error message of the method WebElementFacade.shouldNotContainText.
  • Now you can both activate and deactivate native events for Firefox by setting the thucydides.native.events property to true or false.
  • Thucydides-141: Fixed a bug due to which when trying to open a page with slash in the end of url, browser tried to open page without slash.
21
Feb

Thucydides Release 0.9.98 – Better screenshots management


Thucydides Release 0.9.98 is now out.

More granular screenshot capturing

Adding on to some recent enhancements to screenshots management, Thucydides now supports a method to give you even finer control on capturing screenshots in your tests. Using the newly added takeScreenshot method, you can now instruct Thucydides to take a screenshot at any arbitrary point in the step irrespective of the screenshot level set earlier.

Simply call Thucydides.takeScreenshot() in your step methods whenever you want a screenshot to be captured.

Disk space optimization for reports

Thucydides now saves only rescaled screenshots by default. This is done to help reduce the disk space taken by reports. Should you require to save the original unscaled screenshots too, this default can be easily overridden by setting the property, thucydides.keep.unscaled.screenshots to true.

From this release onwards, html source files for the screenshots will also not be saved by default. Set the property, thucydides.store.html.source to true if you wish to override this behaviour.

Html in step descriptions

This is not really a new feature but rather a hidden feature that one of our users, Alex Artukh, has been experimenting with. You can pass valid HTML text as parameter to @Step methods in the step library. This will show up as formatted text in the reports on the step details page. The following screenshot demonstrates this.

HTML formatted text, if passed to a step method will be displayed as shown. This can be useful for annotating or documenting the tests with helpful information.

HTML formatted text, if passed to a step method will be displayed as shown. This can be useful for annotating or documenting the tests with helpful information.

This was achieved by creating a dummy @Step method called description that takes a String parameter. At runtime, the tests supply this method with formatted html text as parameter.


@Step
public void description(String html) {
    //do nothing
}

public void about(String description, String...remarks) {
    String html =
    "<h2 style=\"font-style:italic;color:black\">" + description + "</h2>" +
    "<div><p>Remarks:</p>" +
    "<ul style=\"margin-left:5%; font-weight:200; color:#434343; font-size:10px;\">";

    for (String li : remarks) html += "<li>" + li + "</li>";

    html += "<ul></div>";

    description(html);
}

Read here for more details.

Incidentally, this feature was broken in the last release due to some regression but has been fixed in the latest release.

Other enhancements

  • Selenium version has been updated to 2.30.0 (Selenium Release notes)
  • WebElementFacade class now has a getAttribute() method to return the value of a given attribute.
  • Continuing with our support for test count based batch strategy from last release, a new system property, thucydides.batch.strategy, has been added to configure the batch strategy. By default this property is set to the value DIVIDE_EQUALLY which divides the test cases equally among batches. Set this property to DIVIDE_BY_TEST_COUNT in order to distribute test cases across batches based on number of test methods in each test case.

Keep watching this space for more.

6
Feb

Thucydides Release 0.9.95 – Example reporting for junit tests


Example reporting comes to Junit tests

Our latest release (0.9.95) brings the example reporting format changes (released last month for jBehave) to parametric junit tests. A few cosmetic changes have also been done for better organization of information and improved readability.

Let’s look at these changes in detail.

Tests table is reorganized to remove clutter.

As the screenshot above demonstrates, the test table on main report page reduces clutter by showing test results at a test-method level instead of a separate row for each parameter set.

Test details page is better organized for readability

Test details page is better organized for readability.

The details page will list all parameter sets in a table. By default, the parameters are names “Parameter 1″, “Parameter 2″ and so on. But this can be configured with a comma separated list of column headings passed as an attribute to the @TestData annotation.


@TestData(columnNames = "Word,Definition")
public static Collection<Object[]> testData() {
  return Arrays.asList(new Object[][]{
    {"apple", "A common, round fruit"},
    {"banana", "An elongated curved fruit"}
  });
}

Further, the steps section will show a collapsed view with a row for each parameter set. The plus  icon can be clicked to expand the top level step to reveal all the steps and corresponding screenshots. Failed test examples will be highlighted in red.

Support for Firefox preferences

A new property firefox.preferences can be used to supply a semicolon separated list of Firefox configuration settings. For ex.,

-Dfirefox.preferences="browser.download.folderList=2;browser.download.manager.showWhenStarting=false;browser.download.dir=c:\downloads"

Integer and boolean values will be converted to the corresponding types in the Firefox preferences; all other values will be treated as Strings. You can set a boolean value to true by simply specifying the property name, e.g. -Dfirefox.preferences=app.update.silent.

For the lazy, here’s a complete reference to Firefox’s configuration settings – http://kb.mozillazine.org/Firefox_:_FAQs_:_About:config_Entries

Support for test count based batch strategy

Thucydides makes it possible to split the web tests into smaller batches, and to run each batch on a different machine or different virtual display. This is achieved by  specifying two parameters when you run each build: the total number of batches being run (thucydides.batch.count), and the number of the batch being run in this build (thucydides.batch.number).

For example, the following will divide the test cases into 3 batches (thucydides.batch.count), and only run the first test in each batch (thucydides.batch.number):

mvn verify -Dthucydides.batch.count=3 -Dthucydides.batch.number=1

However, this strategy divides the test cases equally among batches. This could be inefficient if some of your test cases have more tests than others. This release adds a new batching strategy based on number of tests in the test cases. The strategy is implemented with the help of a TestCountBasedBatchManager which evenly distributes test cases across batches based on number of test methods in each test case.

Follow

Get every new post delivered to your Inbox.

Join 2,764 other followers
